Air Conditioner Bottom Frame Stamping Mold

1.SGCD2
2.The surface needs to be flat, so that the water will not stay on the product.
3.Profile dimensions can be assured and no crack.
4.Control no material overlap from material squeezing and no crack.
5.Through AutoForm R10 simulation analysis,calculate the outer contour edge, make optimization on the cracking position, GDM has made various kinds of bottom frame, with rich experience and technical precipitation.
Availability:
  • SGCD2

  • The surface needs to be flat, so that the water will not stay on the product.

  • Profile dimensions can be assured and no crack.

  • Control no material overlap from material squeezing and no crack.

  • Through AutoForm R10 simulation analysis,calculate the outer contour edge, make optimization on the cracking position, GDM has made various kinds of bottom frame, with rich experience and technical precipitation.

Advantages of air conditioner bottom frame stamping mold


Product name: Bottom Frame

Product material: SGCD2


Product features

As an important supporting structure of air conditioner, the chassis requires a flat surface to ensure that water does not stay on the product when it passes through. This requires the die to accurately control the shape of the product during the stamping process to avoid any defects that may cause water flow stagnation.


Processing accuracy

The die processing accuracy requires that the appearance contour dimensions must be accurately guaranteed, and the product must not crack. To achieve this standard, the die must have extremely high processing accuracy to ensure the mirror finish of the drawing shape and avoid scratches and other surface defects.


Technical highlights

The technical highlights of the chassis include precise control of the step height to avoid material accumulation and double-layer overlap during the molding process. Through CAE analysis and simulation, the die can complete the molding embossing in one go, ensuring that the product has no cracking problems and maintains good appearance quality.


GDM advantages

GDM uses AutoForm R10 simulation analysis technology to optimize the die design stage by reversely calculating the outer contour edge and cracking position. This precise CAE analysis can effectively avoid potential molding defects. GDM has accumulated rich experience and technical accumulation in chassis product manufacturing, and can provide stable trimming and punching structures to ensure the efficiency and reliability of the mold in long-term production.


Other notes

The chassis stamping mold ensures the excellent performance of the product in actual production through advanced CAE simulation technology and stable processing technology. This not only meets the strict requirements of the product for flatness and appearance quality, but also improves production efficiency and the service life of the mold. GDM's professional technology and experience provide a solid guarantee for the high-quality production of chassis molds.


We are a professional home appliance mold manufacturer with a dual background of China Gree Electric and Japan Daikin Industries. With many years of mold experience and superb technology, we can provide high-quality and stable mold solutions for your products.
